letter scale Schütte & Pöppe | This letter scale came badly battered in my possession. A weighing dish or letter plate is missing. The dial has accumulated a lot of cracks and small parts of the enamel are gone. The pointer is bent. The cast iron housing also appears to have been broken and repaired. The green paint is applied over the repair.I do not know whether the scale originally was green. On the dial the holes for the screws became too large for both screw heads, the heads of the screws pass through the holes and securing the dial with these screws does not work anymore. One of the two tension springs of the scale mechanism is missing. I made a weighing dish and repaired and completed the dial with enamel paint. I have reduced the size of the screw holes by gluing a brass plate to the back side of the dial. I placed a replacement spring and oriented and adapted the pointer. For the time being I have postponed a further refinement of the repair. The model of this letter scale can be found in scales of Emil übrig from Berlin and George Salter & Co. from West Bromwich, England. | back of the letter scale |
I tracked down the logo with the horse on the internet, I found it in the letterhead of an invoice of January, 16 1909 of Schütte & Pöppe, Fabrik hauswirtschaftl. Machines, from Hannover-Linden in Germany. This company was founded in 1890. I do not know whether the horse of this logo is a thoroughbred horse, a true Hanoverian. The brand name Hannovera is printed in red on this invoice, it is not on my letter scale. In the documentation database of Ritzo Holtman about weighing scales Hannovera is a brand mentioned in a pricelist of Wirtschaftsgemeinschaft Deutscher Waagen- und Gerätefabriken WIDEWAG G.m.b.H. from Hannover. In this price list from 1930 is the same logo with the horse on top of the text FABRIK=MARKE. In a price list from 1934, the same logo with the horse above the text FABRIK=MARKE, however the factory name is now changed to Hannovera Waagen- und Maschinenfabrik GmbH from Hannover-Linden. Below some pictures of the old battered letter scale and the letterhead of Schütte & Pöppe.
logo of Schütte & Pöppe from the letterhead |
letterhead of Schütte & Pöppe from January, 1909 (source: Wikimedia Commons) | the name of the firm Schütte & Pöppe in the letterhead above this in red is the brandname Hannovera |
animation: the dial before and after a repair |
animation: the logo before and after a repair | animation: back of the dial before and after a repair |
Porto - Taxe left the domestic German postal rates and right the German postal rates to countries of the Weltpostverein |
the somewhat restored dial | the rate limit of 20 grams is given separately the weighing range is 1000 grams |
there are graduations per five grams under Waarenproben (= samples) is the weight limit of 350 grams which is characteristic up to July 1, 1906 |
from the left |
dish added by me |
from the right |
the rusty interior |
the characteristic backside |
the letter scale stands on three supports |
