PRADEL
letter scale / pèse-lettres / pesacartas

design: Pradel, Paris, France
country of origin Spain
bruine lijn
back of the letter scale
back of the PRADEL letter scale


The engraving on this gracefully shaped letter scale reads pesacartas followed by the name PRADEL. Pesacartas is Spanish for letter scale. The unit of measure is GRAMOS, Spanish for gram. This model is more often seen with the text pèse-lettres followed by the name PRADEL, and near the pointer suspension also the word DÉPOSÉ. This letter scale design is originally from France and probably designed by PRADEL. These French scales have GRAMMES as the unit of measure, French for grams. Several versions exist. Er zijn verschillende uitvoeringen. Usually, the weighing range goes up to a maximum of 50 grams, but there are also those which weigh up to 60 grams. There are versions with a stripe of measure per each gram up to 20 grams. Other versions, like the one shown here, have less stripes of measure. Remarkable is the separate indication of 7½ grams. This postal weight limit existed in France until January 1, 1862 and was then changed and raised to 10 grams. I (yet) don't know the Spanish postal weight limits. Some versions of the Pradel letter scale have the postal rates in centimes underneath the weight in grammes, 20 centimes up to 10 grammes, 40 centimes up to 20 grammes, and 80 centimes above 20 grammes (up to 100 grammes). These are the French postal rates for letters valid of the period January, 1862 up to January 1, 1871.
The Pradel also exists with a stand for ease of use. Page 2770 of the journal Equilibrium shows a pillar version with top plate, parallelogram mechanism and stand. My Spanish Pradel letter scale lacked the suspension arm and the letter clip. I complemented the letter scale with home made parts. I made them entirely of brass because it looks better. Probably, the



voorkant weger
PRADEL letter scale


letter clips originally were made of spring steel. The suspension, the pointer arm and also the letter clip of other copies appear to be blackened.
According to an old original packaging, see at bottom of this page, the Pradel letter scale was originally also intended to use as a coin weight checker. This box shows the weight of silver and gold French coins.
Below are some more pictures of my elegant Spanish PRADEL letter scale.

letter scale
with one credit card in the letter clip


the letter clip
this letter clip is made
of a single brass rod

letter scale
three credit cards held by the letter clip


detail 1
PESACARTAS PRADEL

detail 2
firmly between the fingertips

detail 3
this scale has the values 50, 40, 30, 25, 20, 15,
10, 7½, 5, and 0 GRAMOS (Spanish for gram)

detail 4
test with weight of 20 grams

detail 5
the pointer indicates 20 grams

detail 6
test with weight of 50 grams

detail 7
PESACARTAS PRADEL

detail 8
a clear point in the viewport of the indicator arm

detail 9
PESACARTAS PRADEL

wegerdoosje
packing box of a Pradel letter scale


wegerdoosje
weights of French coins
of silver and of gold
